JA94-xx1 Dual Audio Controller

Data Sheet

Description

The JA94-001 dual audio controller is a compact, lightweight unit that incorporates the
latest technology, and is compatible with the current industry standard interconnect. The
unit will support 8 users: pilot, co-pilot and up to 6 passengers. By using a Windows®
based application (ProCSâ„¢), configuration settings may be changed via a 3.5mm jack
on the front panel. Field replaceable illuminated legends (either standard white or NVG
compatible) mean that the dealer only needs to order one version of the controller for
many different mission configurations.

Features

•	 6 transceivers                                                                                                                    •	 4 Receivers
•	 Up to 8 users                                                                                                                     •	 3 Direct inputs
•	 Field configurable settings                                                                                                       •	 5.48 inches [139mm] depth behind
•	 Field replaceable legends                                                                                                         	 panel (not including connectors)
•	 Standard white or NVG compatible                                                                                                  •	 Individual mic. gating
•	 Adjustable output and input levels                                                                                                •	 Tx capability for pilot, co-pilot and
•	 Balanced ICS, CVR, Rx Comp. &                                                                                                     	 up to 3 passengers
	 transmit mic. outputs                                                                                                              •	 Transmit select annunciators
•	 Adjustable CVR output level                                                                                                       •	 Simulcast TX capability
•	 Front panel music input                                                                                                           •	 Connector pin compatible with industry
•	 5,14 and 28 Vdc lighting voltage selection                                                                                        	standard
•	 Music muting                                                                                                                      •	 External pilot/copilot ICS isolation
•	 Duplex mode transmission for telephone	                                                                                           •	 Remote transmit selection
	operation                                                                                                                           •	 ICS PTT for all 8 users
                                                                                                                                     •	 COM6 artifical side tone
