Features

The wiJAC2™ system is designed to be compatible with most general (aviation-type) high impedance headsets.
In-line adapters for use with a low impedance military style audio system are available from Jupiter Avionics.
A light on each unit indicates when the RF communication link is established, and a 2.1mm coaxial charging port is
provided for connection to a USB charging source.
The base unit has a 10 pin HIROSE connector and the headset unit has a 6 pin LEMO connector.
Adapter cables for NATO style aircraft connectors, charging cables and rechargeable batteries are included with each
system.
Multiple paired adapters can be co-located in the same aircraft without interference. An encrypted radio link ensures
secure communications. Alternative adapter cables are available for use with other connector styles.
The wiJAC2-001 system comprises a JB60-001 and a JB69-001 and is for use in North America.
The wiJAC2-002 system comprises a JB60-002 and a JB69-002 and is for European use.

TM
- 0xx Specifications

Installation

JAC 04-27-21 TAT JAC 05-17-21 KDV

JB60 Wireless Aircraft Headset Adapter JB69 Wireless Aircraft Intercom Adapter
Weight: 0.79 lbs [0.36 kg] MAX. with batteries Weight: 0.74 lbs [0.33 kg] MAX. with batteries

Environment and Performance

Batteries 6 ea. AA, (3 per unit) Vibration Per DO160G
Charging Electrical +5 Vdc @ 200mA max Cat [(SBM)(U2FF1)]
Power (USB Power Source) Range wiJAC2-001 Up to 328 ft [100 m]
Microphone 150 Ohms amplified (unobstructed)
Dynamic Range wiJAC2-002 Up to 984 ft [300 m]
(unobstructed)
Battery Life 6 to 8 hr (typical)
Headphone 240 mW into 150 Ohms
