Page 7 - Product Guide Rev H
P. 7

JA94-xx2A Specifications

               Installation                                                       5.00in MAX










                                                                                127.0mm MAX





                                                                                                   1.88in MAX  47.8mm MAX











                                                                                   5.48in MAX
                                                                                   139.2mm MAX
                                       5.75in MAX
                                     146.1mmMAX


               Weight: 1.99 lb. [0.91 kg] Max.

               JA94-0x2A Standard White Lighting
               JA94-Nx2A NVG Compatible
                                          UNLESS OTHERWISE SPECIFIED  PREPARED  TAT
                                          DIMENSIONS ARE IN INCHES
                                          ANGLES ARE IN DEGREES
                                          TOLERANCES:               JAC
                                          1 DEC PLACE:     0.1  CHECKED  06-22-16
               Environment and Performance                          TAT  TITLE     Dual Audio Controller - Front Panel ICS ISO
                                          2 DEC PLACE:     0.01
                                          3 DEC PLACE:     0.005
                                          ANGLES:
                                                    0.5 DEG
                                                                    JAC
                                                          APPROVED  06-22-16  NCAGE CODE  PART NO.                   SHEET
                                                                          L00N3
                                                                    KDV
                Transceivers                             5 Comm. transceivers      JA94-002                          1/1
                                                          CONFIDENTIAL & PROPRIETARY DOC.  NO.
                Receiver Input            MATERIAL: N/A  4 Receivers + 4 Direct, 2 Music Inputs, 1 ICS Tie
                                                                         JA94-002 3D Model Rev A.SLDDRW
                                                           TO JUPITER AVIONICS CORP.
                                             N/A
                                          FINISH:
                                                            DRAWING NOT TO SCALE
 JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT
                Number of Headsets                       8 users: Pilot, Co-pilot, 6 passengers
                Electrical                       Power    0.95A @ 28 Vdc max
                                                     Lighting  <10mA @ 5, 14, 28 Vdc
                Temperature                 Operational  -45 °C to +70 °C
                                                     Survival  -55 °C to +85 °C
                Altitude                                 55,000 ft. max
                Humidity                                 95%
                Shock                                    6g (any axis)
                Headphone                                125 mW into 600 ohms
                TSO Compliance                           TC CAN-TSO-C139
                Installation Kit                         INST-JA94




                                              © 2018 Jupiter Avionics Corporation
               TM
                                           1959 Kirschner Rd, Kelowna, BC V1Y 4N7
                                         Tel: (778) 478-2232   Toll-Free: (855) 478-2232
       Printed in Canada                          www.jupiteravionics.com
