Page 9 - Product Guide Rev H
P. 9

JA94-x44A Specifications

               Installation                                                       5.00in MAX










                                                                                127.0mm MAX




                                                                                                    1.875in MAX  47.63mm MAX












                                                                                   5.48in MAX
                                                                                   139.2mm MAX
                                       5.75in MAX
                                     146.1mmMAX


               Weight: 1.99 lb. [0.91 kg] Max.


               JA94-044A Standard White Lighting
               JA94-N44A NVG Compatible
                                          UNLESS OTHERWISE SPECIFIED  PREPARED  TAT
                                          DIMENSIONS ARE IN INCHES
               Environment and Performance                          JAC
                                          ANGLES ARE IN DEGREES
                                          TOLERANCES:
                                          1 DEC PLACE:    0.1
                                          2 DEC PLACE:   0.01  CHECKED  05-05-16  TITLE
                                          3 DEC PLACE:   0.005      TAT
                                          ANGLES:  0.5 DEG                         Dual Audio Controller - AMS44 Compatible
                Transceivers                             6 Comm. transceivers
                                                                    JAC
                                                          APPROVED  05-05-16  NCAGE CODE  PART NO.                   SHEET
                Receiver Input                           4 Receivers + 3 Direct, 2 Music Inputs, 1 ICS Tie           1/1
                                                                          L00N3
                                                                                   JA94-044
                                                                    KDV
                                                          CONFIDENTIAL & PROPRIETARY DOC.  NO.
                Number of Headsets        MATERIAL: N/A  8 users: Pilot, Co-pilot, 6 passengers
                                                           TO JUPITER AVIONICS CORP.
                                          FINISH:  N/A      DRAWING NOT TO SCALE  JA94-044 3D Model Rev A.SLDDRW
                Electrical                       Power   0.95A @ 28 Vdc max
 JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT
                                               Lighting  <10mA @ 5, 14, 28 Vdc
                Temperature                 Operational  -45 °C to +70 °C
                                               Survival  -55 °C to +85 °C
                Altitude                                 55,000 ft. max
                Humidity                                 95%
                Shock                                    6g (any axis)
                Headphone                                250 mW into 600 ohms
                TSO Compliance                           Contact JAC for TSO status
                Installation Kit                         INST-JA94







                                              © 2017 Jupiter Avionics Corporation
                   TM
                                           1959 Kirschner Rd, Kelowna, BC V1Y 4N7
                                          Tel: 778-478-2232   Toll-Free (855) 478-2232
          Printed in Canada                       www.jupiteravionics.com
