JRS12-001 Relay Switch - 12 Poles
JRS14-001 Relay Switch - 14 Poles
Data Sheet
Description
The JRS12-001 / JRS14-001 Relay Switches are compact, high density, bulkhead
mounted remote switching units designed to handle the switching requirements of
navaid, audio or other interface applications. Both the JRS12 and JRS14 allow large
numbers of data or audio lines to be transferred with a single control line. All relay
switches have a contact rating of 1 amp / 30 vdc and are mechanical.
The JRS12 includes circuitry for flag load resistors and flag bias generators.
The JRS14 includes 2 extra poles of switching contacts and 1 flag bias generator.
