JRS24-001 Data Transfer Switch
JRS28-001 Data Transfer Switch
Data Sheet
Description
The JRS24-001 / JRS28-001 Transfer Switches are compact, high density, bulkhead
mounted remote switching units designed to handle the switching requirements of
navaid, audio or other interface applications. Both the JRS24 and JRS28 allow large
numbers of data or audio lines to be transferred with a single control line. All relay
switches have a contact rating of 1 amp / 30 vdc.
The JRS24 includes circuitry for flag load resistors and flag bias generators.
The JRS28 includes 4 extra poles of switching contacts and 2 flag bias generators.
