JA94-xx2A Dual Audio Controller

Data Sheet

Description

The JA94-002A dual audio controller is a compact, lightweight unit that incorporates the
latest technology, and is compatible with the current industry standard interconnect. The
transceiver selection order is the same as the AMS44. The unit will support 8
users: pilot, co-pilot and up to 6 passengers. By using a Windows® based application
(ProCS™), configuration settings may be changed via a 3.5mm jack on the front panel.
Field replaceable illuminated legends (either standard white or NVG compatible) mean
that the dealer only needs to order one version of the controller for many different
mission configurations.
Features

• 5 transceivers • 4 Receivers
• Up to 8 users • 4 Direct inputs
• Field configurable settings • 5.48 inches [139mm] depth behind
• Field replaceable legends panel (not including connectors)
• Standard white or NVG compatible • Individual mic. gating
• Adjustable output and input levels • Tx capability for pilot, co-pilot and
• Balanced ICS, CVR, Rx Comp. & up to 3 passengers
transmit mic. outputs • Transmit select / ISO annunciators
• Adjustable CVR output level • Connector pin compatible with industry
• Front panel music input standard
• 5,14 and 28 Vdc lighting voltage selection • Pilot / Copilot ICS isolation switches
• Music muting • Remote transmit selection
• Duplex mode transmission for telephone • ICS PTT for all 8 users
operation
