JA30-001 Volume Control Panel

Data Sheet

Description

The JA30-001 Volume Control panel provides individual volume control and on / off
selection for up to nine audio channels. The volume knobs provide the push on / push
off facility for each audio channel.

A passive emergency mode provides a direct connection between audio input and out-
put for two channels.

Each channel has a receive signal detection indicator and all selected audio channels
are summed to a composite output.

Features

• Compact, lightweight design
• Field replaceable front panel legends
• Legends dimmable from the 28 Volt lighting bus
• Normal and Emergency mode
