Page 65 - Jupiter Product Guide 2024 Rev M

JA30-001 Specifications

Installation

JA30-001

JA10-001

4.92in MAX
125.0mm MAX

1.125in MAX
28.6mm MAX

3.92in MAX
99.6mm MAX
5.75in MAX
146.1mm MAX
Weight: TBD
Environment and Performance
UNLESS OTHERWISE SPECIFIED PREPARED TAT
DIMENSIONS ARE IN INCHES
ANGLES ARE IN DEGREES
TOLERANCES:
Electrical Power 2 DEC PLACE: 28 Vdc @ 130 mA typical
1 DEC PLACE: 0.1
CHECKED
TITLE
0.01
3 DEC PLACE:
0.5 DEG
ANGLES: 0.005 Volume Control Panel
Operating Temperature -40 C to +70 C
APPROVED NCAGE CODE PART NO. SHEET
JA30-001
1/1
L00N3
Survival Temperature MATERIAL:-55 C to +85 C
CONFIDENTIAL & PROPRIETARY DOC. NO.
N/A
FINISH: N/A TO JUPITER AVIONICS CORP. JA30-001 3D Model Rev A.SLDDRW
DRAWING NOT TO SCALE
Altitude JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT 50,000 ft. max
Humidity 95%, 48 hrs
Shock 20 g (any axis)
TSO Compliance Contact JAC for TSO status
Installation Kit INST-JA30
© 2019 Jupiter Avionics Corporation
TM
1959 Kirschner Rd, Kelowna, BC V1Y 4N7
Tel: 778-478-2232 Toll-Free (855) 478-2232
Printed in Canada www.jupiteravionics.com
