Page 59 - Jupiter Product Guide 2024 Rev M

JA23-001 Block Diagram

INPUTS OUTPUT

AUDIO 1

AUDIO 2

AUDIO 3

MIC

PTT

VOLUME

MUTE

JA23-001 Specifications

Installation

1.38in MAX
35.1mm MAX
6.30in MAX
160.0mm MAX
Weight: 0.68 lb. [0.31 kg] Max.
2.60in MAX
66.0mm MAX
Environment and Performance

Electrical Power 28 Vdc @ 1.0 A typical
UNLESS OTHERWISE SPECIFIED
Operating Temperature -45 °C to +70 °C PREPARED TAT
DIMENSIONS ARE IN INCHES
ANGLES ARE IN DEGREES
TOLERANCES: 0.1 JAC
1 DEC PLACE:
Survival Temperature -55 °C to +85 °C CHECKED 04-23-18 TITLE Speaker Amplifier
2 DEC PLACE:
0.01
3 DEC PLACE:
0.005
TAT
ANGLES:
0.5 DEG
JAC
Altitude 50,000 ft. max APPROVED 04-24-18 NCAGE CODE PART NO. SHEET
KDV L00N3 JA23-001 1/1
Shock, Crash Safety 6g, 20g for 11ms CONFIDENTIAL & PROPRIETARY DOC. NO.
N/A
MATERIAL:
TO JUPITER AVIONICS CORP.
FINISH: N/A DRAWING NOT TO SCALE JA23-001 3D Model Rev B.SLDDRW
TSO Compliance Contact JAC for TSO status
JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT
Installation Kit INST-JA23
