JA31-x01 Intercom Bus Selector
Data Sheet
Description
The JA31-x01 Intercom Bus Selector provides the aircrew with the ability to manage the
intercom between audio controllers in the aircraft. Using the front panel switches, three to six
audio controllers’ ICS TIE lines are connected to either of two intercom buses which
allows individuals to be isolated, or for different intercom talk groups.
Impedance load matching is provided so that ICS TIE line audio levels are maintained.
Features
• NO aircraft power required • Legends dimmable from the aircraft
• Interchangeable front panel legends lighting bus
• Pin compatible with industry standard
