Page 69 - Jupiter Product Guide 2024 Rev M

Normal Mode, One Group Normal Mode, Two Groups

INPUTS OUTPUTS INPUTS OUTPUTS
1 1

2 1 PRIORITY 1 - 3 2 1

PRIORITY 1 - 6 3 4 3 4

PRIORITY 4 - 6
5 2 5 2

6 6

Emergency Mode, Both Groups

INPUTS OUTPUTS
1 1

2

3

4 2

5

6
JA35-100 Specifications

Installation

1.27in MAX 32.3mm MAX

4.42in MAX
112.3mm MAX
3.52in MAX
89.4mm MAX
Weight: 1.00 lb. [0.45 kg] Max. 114.8mm MAX
4.52in MAX
Environment and Performance

Electrical Power 22 Vdc @ 1.0 A Max
Operating Temperature -40 C to +70 C UNLESS OTHERWISE SPECIFIED PREPARED TAT
DIMENSIONS ARE IN INCHES
ANGLES ARE IN DEGREES
TOLERANCES:
1 DEC PLACE: 0.1
Survival Temperature -55 C to +85 C 2 DEC PLACE: 0.01 CHECKED TITLE
3 DEC PLACE:
0.005
ANGLES: 0.5 DEG Audio Summing Amplifier - Remote Mount
Altitude 50,000 ft. max
APPROVED NCAGE CODE PART NO. SHEET
Humidity 95%, 48 hrs L00N3 JA35-100 1/1
MATERIAL:
CONFIDENTIAL & PROPRIETARY DOC. NO.
N/A
TO JUPITER AVIONICS CORP. JA35-100 3D Model Rev A.SLDDRW
N/A
Shock JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT 20g (any axis) DRAWING NOT TO SCALE
FINISH:
TSO Compliance CAN CAN-TSO C139 (Pending)
Installation Kit INST-JA35
© 2016 Jupiter Avionics Corporation
TM
1959 Kirschner Rd, Kelowna, BC V1Y 4N7
Tel: 778-478-2232 Toll-Free (855) 478-2232
Printed in Canada www.jupiteravionics.com
