JA84-001 Audio Junction Panel

Data Sheet

Description

The JA84-001 Audio Junction Panel is a centralized management system that
distributes transceiver, receiver, ICS, music and warning source audio signals in an
aircraft for up to four audio control panels.

The JA84-001 is compatible with most Jupiter and other manufacturers’ analogue audio
control systems.
Features

The JA84-001 supports up to:
• Five audio control panels
• Ten transceivers.
• Six receivers.
• Four direct audio inputs.
• Four music inputs.
• Five ICS Tie Lines in parallel or individual to an ICS Selector panel.
• Four descrete Alert inputs. TO ONLINE INFO
