Page 75 - Jupiter Product Guide 2024 Rev M

JA94-R62A Specifications

Installation

1.97in MAX 50.0mm MAX

5.87in MAX
149.1mm MAX
6.79in MAX
172.5mm MAX

Weight: 1.90 lbs [0.86 kg] Max.

UNLESS OTHERWISE SPECIFIED PREPARED TAT
DIMENSIONS ARE IN INCHES
ANGLES ARE IN DEGREES
TOLERANCES: JAC
1 DEC PLACE: 0.1
2 DEC PLACE: 0.01 CHECKED 11-13-19 TITLE
3 DEC PLACE: 0.005 TAT
ANGLES: 0.5 DEG Dual Audio Controller - Remote Mount - Mixing
JAC Amplifier
Environment and Performance APPROVED 11-19-19 NCAGE CODE PART NO. SHEET
KDV L00N3 JA94-R62A 1/1
MATERIAL: N/A CONFIDENTIAL & PROPRIETARY DOC. NO.
TO JUPITER AVIONICS CORP.
JA94-R62A 3D Model Rev A.SLDDRW
Rated Input Level FINISH: N/A 1 to 10 Vrms for mixer 3 inputs 1 and 2
DRAWING NOT TO SCALE
JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT
1 to 10 Vrms for mixer 1 and 2 inputs 1 thru 5
0.25 Vrms for mixer 1 and 2 inputs 6
Rated Output Level, Mixers 1 & 2 8.7 Vrms +/- 10%
Rated Output Level, Mixer 3 2.50 Vrms +/- 10%
Audio Frequency Response ≤ 3dB from 300 to 6000 Hz
Electrical Power 22 to 32.2 Vdc, 1.5A to 0.95A max
Temperature Operational -45 °C to +70 °C
Survival -55 °C to +85 °C
Altitude 50,000 ft. max
Humidity 95%
Shock 6g (any axis)
TSO Compliance TC CAN-TSO C139

Installation Kit INST-94R62

© 2019 Jupiter Avionics Corporation
TM
1959 Kirschner Rd, Kelowna, BC V1Y 4N7
Tel: 778-478-2232 Toll-Free (855) 478-2232
Printed in Canada www.jupiteravionics.com
