Page 71 - Jupiter Product Guide 2024 Rev M

JA55-015

Installation

4.92in MAX

3.00in MAX 76.2mm MAX 125.0mm MAX

5.75in MAX
2.07in MAX
146.1mm MAX
Weight: TBD lb. TBD Kg Max 52.6mm MAX

Environment and Performance
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES PREPARED TAT
ANGLES ARE IN DEGREES
TOLERANCES:
1 DEC PLACE: 0.1
2 DEC PLACE: 0.01 CHECKED TITLE
ANGLES: 0.5 DEG 15
Maximum power (Watts) 3 DEC PLACE: 0.005 Dzus Panel Speaker - 4 Ohm - 15 Watt
Rated Impedance (Ohms) 4
APPROVED NCAGE CODE PART NO. SHEET
Frequency Range (Hz) 150 - 20,000 L00N3 JA55-015 1/1
Operating Temperature MATERIAL: N/A -45 °C to +70 °C DOC. NO.
CONFIDENTIAL & PROPRIETARY
TO JUPITER AVIONICS CORP.
Survival Temperature FINISH: N/A -55 °C to +85 °C JA55-015 3D Model Rev A.SLDDRW
DRAWING NOT TO SCALE
JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT

Installation Kit INST-JA55
