Page 73 - Jupiter Product Guide 2024 Rev M

JA84-001 Specifications

Installation

6.13in MAX
155.7mm MAX
1.73in MAX 43.9mm MAX

0.75in
19.1mm
0.60in 4.89in 0.21 x 8
15.2mm 124.1mm 0.38in
5.4 9.5mm

9.57in MAX 243.1mm MAX 8.95in 227.3mm 8.95in 227.3mm

0.30in 7.6mm Weight: TBD 0.30in 7.6mm

Environment and Performance

Operating Temperature -40 C to +70 C
UNLESS OTHERWISE SPECIFIED PREPARED TAT
DIMENSIONS ARE IN INCHES
Survival Temperature 1 DEC PLACE: 0.1 -55 C to +85 C
ANGLES ARE IN DEGREES
TOLERANCES:
CHECKED
Altitude CENTER OF GRAVITY 2 DEC PLACE: 0.01 50,000 ft. max TITLE Audio Junction Panel
3 DEC PLACE:
0.005
0.5 DEG
ANGLES:
0.03in [0.8mm]
Humidity WEIGHT: TBD lbs [TBD kg] MAX. 95%, 48 hrs NCAGE CODE PART NO. SHEET
APPROVED
JA84-001
1/1
L00N3
MATERIAL: N/A CONFIDENTIAL & PROPRIETARY DOC. NO.
Shock FINISH: N/A 20 g (any axis)
JA84-001 Mechanical Installation Rev A.SLDDRW
TO JUPITER AVIONICS CORP.
DRAWING NOT TO SCALE
JUPITER AVIONICS TEMPLATE SOLIDWORKS PORTRAIT SIZEB REV B.DRWDOT
TSO Compliance Contact JAC for TSO status
Installation Kit INST-JA84
© 2019 Jupiter Avionics Corporation
TM
1959 Kirschner Rd, Kelowna, BC V1Y 4N7
Tel: 778-478-2232 Toll-Free (855) 478-2232
Printed in Canada www.jupiteravionics.com
