JA94-R62A Dual Six Channel Mixing Amplifier

Data Sheet

Description

The JA94-R62A mixing amplifier is a compact, lightweight unit that incorporates the
latest technology. The unit will mix up to six input signals into one output and up to six
different inputs into a second output. A third mixer combines two further input signals
into two separate outputs.

A passive emergency mode connects two pairs of input signals directly to each of two
mixer outputs.By using a Windows based application (ProCS ), configuration settings
®
TM
may be changed via a 3.5mm jack, even after installation in the aircraft.

Features

• Two Mixers, each with up to six inputs
• Field configurable settings
• One Mixer with two inputs and two outputs
• Passive Emergency mode operation
