eqJAC-001 Headphone Audio Notch Filter
Data Sheet
eqJAC-001
The eqJAC-001 Headphone Audio Notch filter allows the user to select manually a
narrow band of unwanted frequencies to be removed from the headphone audio.
Features
The eqJAC-001 has one control to adjust the center frequency of the notch filter.
The eqJAC-001 operates using four AA batteries and requires no other external power.
The eqJAC-001 unit features an industry standard U-174/U (TP-120) plug to interface
with a high impedance audio panel, and supports an automatic on/off power function
that senses the intercom microphone bias voltage, allowing the user to unplug the unit
from the aircraft to turn power off.
