JA23-001 Speaker Amplifier - 10 Watt

Data Sheet

Description

The JA23-001 is a 10 Watt remote mount speaker amplifier with an external volume
control which allows the crew to monitor receive audio in the aircraft cabin.

Three differential audio inputs allow mixing of audio before being routing to output port.
A separate single ended microphone input with mic bias allows direct connection to
legacy audio panels.

Features

• Single speaker output with up to 10 Watts of audio power.
• Supports common network loudspeaker impedances of 3.2 Ohms and higher.
• Three differential audio inputs are provided with allowable input levels from
1Vrms to 2.5Vrms.
• One microphone input with bias voltage.
• 30 dB of adjustable output
• Supports both speaker mute and Push-to-talk functions.
