Page 15 - Jupiter Product Guide 2024 Rev M

JA94-xx2A Specifications

Installation 5.00in MAX

127.0mm MAX

1.88in MAX 47.8mm MAX

5.48in MAX
139.2mm MAX
5.75in MAX
146.1mmMAX

Weight: 1.99 lb. [0.91 kg] Max.

JA94-0x2A Standard White Lighting
JA94-Nx2A NVG Compatible
UNLESS OTHERWISE SPECIFIED PREPARED TAT
DIMENSIONS ARE IN INCHES
ANGLES ARE IN DEGREES
TOLERANCES: JAC
1 DEC PLACE: 0.1 CHECKED 06-22-16
0.01
2 DEC PLACE:
Environment and Performance TAT TITLE Dual Audio Controller - Front Panel ICS ISO
0.005
3 DEC PLACE:
0.5 DEG
ANGLES:
JAC
APPROVED 06-22-16 NCAGE CODE PART NO. SHEET
L00N3
KDV
Transceivers 5 Comm. transceivers JA94-002 1/1
CONFIDENTIAL & PROPRIETARY DOC. NO.
Receiver Input MATERIAL: N/A 4 Receivers + 4 Direct, 2 Music Inputs, 1 ICS Tie
TO JUPITER AVIONICS CORP.
JA94-002 3D Model Rev A.SLDDRW
N/A
FINISH:
JUPITER AVIONICS TEMPLATE SOLIDWORKS LANDSCAPE SIZEA REV B.DRWDOT DRAWING NOT TO SCALE
Number of Headsets 8 users: Pilot, Co-pilot, 6 passengers
Electrical Power 0.95A @ 28 Vdc max
Lighting <10mA @ 5, 14, 28 Vdc
Temperature Operational -45 °C to +70 °C
Survival -55 °C to +85 °C
Altitude 55,000 ft. max
Humidity 95%
Shock 6g (any axis)
Headphone 125 mW into 600 ohms
TSO Compliance TC CAN-TSO-C139
Installation Kit INST-JA94

© 2018 Jupiter Avionics Corporation
TM
1959 Kirschner Rd, Kelowna, BC V1Y 4N7
Tel: (778) 478-2232 Toll-Free: (855) 478-2232
Printed in Canada www.jupiteravionics.com
